Pro2.6 is a dual 15-inch three-way speaker, and the low frequency adopts advanced anti-compression audio technology. Pro2.6 is a further development based on the success of Pro2.5, a high-output full-range speaker optimized for rental or touring applications, it can play a role in a variety of different applications and provide a continuous high boost level and sufficient carrying power. Different from similar products: This product consists of a 1.4″ ultra-high frequency driver and a “3” (74.4mm) titanium high-frequency driver to form a dual high-frequency output system, aiming to obtain a wider range of high-frequency response while increasing its carrying power . Unlike competitors, two 4″ (99.6mm) heat-dissipating voice coils, 220mm magnets, high-power 15″ low-frequency drivers use reverse compression technology, so that better low-frequency limits and higher sensitivity can be obtained. Pro2.6 uses all CAT KING self-developed drive units. The parameters and performance of the units are also tailored by engineers according to their product positioning, and the performance parameters are highly matched. The scientific crossover point and low-loss crossover circuit design will not cause interference even under extremely high sound pressure, and it is highly balanced and highly restores the real sound . The multiple handles on the side and the humanized bottom caster design can save physical strength during heavy touring activities . It is also more convenient and faster to move . Unique titanium gray coating; with ABS shell protection module design, it avoids damage to the equipment during frequent movement.
| Model Name | Pro2.6 |
| Product design | Three-way anti-compression stage speaker |
| Product type | Dual 15-inch full-range passive speakers |
| Rated impedance | 4 Ohm |
| Power handling capability: | |
| Rated power AES (W) | 1400 W |
| Long-term maximum signal power MUSIC (W) | 2800 W |
| Short-term peak power PEAK 10ms (W) | 5600 W |
| Sensitivity | 102 dB SPL 1W@1m |
| Frequency response (+-3dB) | 42 Hz – 18 KHz |
| Frequency response (+-10dB) | 39 Hz – 20 KHz |
| Crossover frequency MH/HF | 2.4KHz / 1.5KHz (passive) |
| Sound pressure level (1M) continuous/maximum dB | 123dB/129dB (calculated value) |
| Driver part | |
| LF low frequency driver: | LF15220F-100 |
| LF Size | 380 mm / 15 in |
| LF voice coil size | 99.6 mm / 4 in |
| LF magnet structure | 220mm Ferrite Coil |
| LF Frame Material | Aluminum cone |
| HF high frequency driver: | HF170F-3 / HF100F-1.4 |
| HF high frequency driver type | Dome Compression Driver |
| HF coil size MH/HF | 74.4 mm (3 inches) / 34.4 mm (1.4 inches) |
| HF port size MH/HF | 38 mm (1.5 in) / 26 mm (1 in) |
| HF high frequency magnet structure MH/HF | 170mm/100mm Ferrite Coil |
| HF diaphragm material | Titanium |
| Horn waveguide type | Integrated constant square double horn |
| Nominal Coverage (HxV) | 110° × 70° |
| Protect | Independent electronic RMS limiting of high frequency signals |
| Box and accessories | |
| Input Connectors | 2 x XLR sockets (1+ / 1-) with junction box |
| Rigging and Hardware | 9 M8 eyebolt mounting points |
| handle | 3 on the side, 1 on the back, 7 in total |
| Box shape | Trapezoidal CNC manufacturing |
| Housing material and surface treatment | 18mm multi-layer birch board |
| Shell coating and color | Titanium grey fine dotted cover |
| Grille Materials and Treatments | Black perforated mesh Moisture-proof and dust-proof acoustic mesh backing |
| Move and protect | 2 casters at the bottom, 2 rubber pads, 2 ABS anti-collision protection strips at the top and bottom |
| Product Dimensions – Unpackaged: | |
| Front height | 1260 mm / 49.61 in |
| Rear height | 1260 mm / 49.61 in |
| Front width | 520 mm / 20.47 in |
| Rear width | 370 mm / 14.57 in |
| depth | 620 mm / 24.41 in |
| Product Dimensions – Packaging: | |
| High | 1300 mm / 51.18 in |
| Front width | 570 mm / 22.44 in |
| Rear width | 410 mm / 16.14 in |
| Depth | 670 mm / 26.38 in |
| weight: | |
| net weight | 72 kg / 158.73 lbs |
| gross weight | 78 kg / 171.96 lbs |
